Terex earthmoving equipment parts
LOW RANGE GEARING & CLUTCHES
NC NO. QTY PART NO. DESCRIPTION
001 001 06831151 SHAFT-SPLITTER
002 001 06756030 ·TUBE
003 001 23047981 BEARING
004 001 06754835 RING-SNAP
005 001 29536124 OUTPUT SHAFT
006 001 06831150 CARRIER ASSY
007 001 06775706 ·CARRIER
008 010 23041007 ·WASHER
009 005 06830333 ·BEARING
010 001 06832007 ·PLANETARY GEAR(FIVE)
011 001 06758541 ·RING-SNAP
012 005 00453606 ·BALL
013 005 06758540 ·PIN ROLL
014 001 06831155 PISTON HOUSING
015 002 06768419 ·PIN
016 001 06758505 WASHER
017 001 06831120 GEAR-LOW
018 001 06759414 MOUNTING DUMP
019 002 06768478 KEY
020 014 06838589 SPRING
021 004 23041616 PLATE-INTER SPLINED
022 004 06768326 PLATE-EXTER SPLINED
023 001 06832484 WASHER
NC NO. QTY PART NO. DESCRIPTION
024 001 06831034 PISTON
025 001 06832486 SEAL
REV RANGE GEARING & CLUTCHES
NC NO. QTY PART NO. DESCRIPTION
001 001 06775716 GEAR-SUN REVERSE
002 006 23016615 BOLT
003 001 06775712 PLATEN
004 001 06775699 WASHER
005 001 06831119 GEAR-REVERSE
006 001 06775718 CARRIER ASSY
007 001 06775717 ·CARRIER
008 012 06768499 ·WASHER
009 012 06769261 ·SPACER
010 001 06776022 ·PLANETARY GEAR(SIX)
011 144 06756275 ·ROLLER
012 006 06775714 ·PIN ROLL
013 001 06832487 ·BALL
014 001 23041147 BEARING
015 001 06759423 MOUTING DUMP
016 014 23017349 SPRING
017 002 06768396 KEY
018 005 23041616 PLATE-INTER SPLINED
019 005 06769326 PLATE-EXTER SPLINED
020 001 06832484 SEAL
021 001 06831032 PISTON
