Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
WhatsApp : 008618264966991
Terex earthmoving equipment parts
| 001 001 15250127 KIT-HAND TOOLS |
| 001 001 15050284 O RING KIT-SAE |
| 001 001 15271082 O RING KIT-ORFS |
| 001 001 15344293 DOCUMENT POUCH & LANYARD 002 001 15344403 BUTT SPLICE 003 001 15344355 BINDER STRIP A 004 001 15501195 OPERATORS MANUAL(ENGLISH) NOTE: A FOR CASTLEBRIDGE TR100’S USE 15504598 OPS. MANUAL |
| 001 001 15500638 BRACKET-PUMP MTG 002 001 15500639 KIT-PRESS WARNING 003 001 15500640 LUBE FTG BLOCK-1 WAY 004 ASR 15500641 8.6MM H/PRESS HOSE-FILLED 005 061 15273165 STUD-HOSE 006 061 15273164 SLEEVE-HOSE 007 016 15273163 ADAPTOR-1/8 EXTENSION 008 003 15273649 ADAPTOR 009 028 15273650 ELBOW 010 008 15500644 PLUG 011 028 15275170 CHECK ASSY (PIF) 012 001 15500645 ILLUM PUSHBUTTON 24V 013 001 15273148 METERING BLOCK-SSV8K 014 001 15273150 METERING BLOCK-SSV12 015 002 15273149 METERING BLOCK-SSV8 016 001 15273146 VALVE-SAFETY 017 001 15275629 ADAPTOR-SAFETY VALVE 018 001 15274307 GREASE PUMP 019 001 15273145 .KIT-REPAIR 24V MOTOR 020 001 15274943 .RESERVOIR 8 LITRE 021 001 15275348 .PUMP ELEMENT WITH ASSY 022 001 15275349 .VDC CONTROL CARD |
| 000 001 15023975 EXTINGUISHER & BRKT 001 001 15267175 .CARTRIDGE-RECHARGE 002 004 00179839 BOLT 003 004 00108580 LOCKWASHER 004 004 00102635 NUT |
| 001 001 15023975 EXTINGUISHER & BRACKET 002 001 15267175 .CARTRIDGE 003 001 15504585 .BRACKET 004 014 07151020 WASHER 005 006 06351025 BOLT 006 008 06471001 LOCKNUT 007 002 06351030 BOLT 008 001 15352162 BRACKET-MOUNTING 009 002 15302982 U-BOLT |
| 001 001 15303889 FRAME ASSY COMPLETE T7831479 T7831532 002 002 09011828 .BUSHING 001 001 15359598 FRAME ASSY COMPLETE T7831533 002 002 09011828 .BUSHING 003 001 15247058 GUARD-ENGINE 004 001 15252399 GUARD-TRANS 005 008 09355771 NUT 006 016 09176228 WASHER-HARDENED 007 008 00223464 BOLT 008 008 15020053 WASHER-HARDENED 009 008 00223453 BOLT 010 008 00274141 NUT 011 008 15250985 SPRING-DISC 012 008 15303749 WASHER-HARDENED 013 008 15303750 SPACER-HARDENED |
| 17 | 9079588 | PISTON |
| 18 | 9068667 | BOLT |
| 19 | 9015066 | TUBE ASSEMBLY |
| 20 | 9167506 | BEARING |
| 21 | 9425517 | RING-SNAP |
| 22 | 6525035 | VALVE ASSY-RECHARGE |
| 23 | 9030336 | RING-LARGE |
| 24 | 9034883 | CORE |
| 25 | 179837 | BOLT |
| 26 | 9078692 | BOOT |
| 27 | 9078136 | PLATE |
| 28 | 9139822 | CLAMP |
| FRONT WHEEL, RIM AND TYPE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9270229 | WHEEL |
| 2 | 9253468 | STUD |
| 3 | 9250686 | RING |
| 4 | 9016971 | WASHER |
| 5 | 9433277 | CONE-INNER BEARING |
| 6 | 9433278 | CUP-INNER BEARING |
| 7 | 15231599 | VALVE EXTENSION |
| 8 | 15004075 | BASE |
| 9 | 9195954 | FLANGE |
| 10 | 9012404 | BAND-BEAD SEAT |
| 11 | 9003669 | LOCK RING |
| 12 | 9003519 | O RING |
| 13 | 15230597 | VALVE STEM |
| 14 | 9142286 | CORE |
| 15 | 9116292 | CAP |
| 16 | 9432641 | CUP-OUTER BEARING |
| 17 | 9432640 | CONE-OUTER BEARING |
| 18 | 9253679 | SHIM .005 |
| 19 | 9253681 | SHIM .020 |
| 20 | 9253680 | SHIM .007 |
| 21 | 9253619 | PLATE |
| 22 | 9253620 | BOLT |
| 23 | 9115806 | CAP-HUB |
| 24 | 179881 | BOLT |
| 25 | 103329 | LOCK WASHER |
| 26 | 9433576 | NUT |
| 27 | 9016973 | SEAL |
| 28 | 15023746 | CLAMP |
| 29 | 9113457 | LOCK WIRE |
| 30 | 9207478 | GASKET |
| FRONT AXLE SLACK ADJUSTER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15014970 | ADJUSTER-SLACK RH |
| 2 | 9039926 | RIVET |
| 3 | 9039910 | COVER |
| 4 | 9039912 | GEAR-WORM |
| 5 | 9024901 | WORM |
| 6 | 9033031 | SHAFT |
| 7 | 9054078 | BUSHING |
| 8 | 9411010 | FITTING-GREASE |
| FRONT RIDE CYLINDER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9079452 | FRONT RIDE CYLINDER |
| 2 | 6525035 | VALVE ASSY-RECHARGE |
| 3 | 9013688 | VALVE-CHECK |
| 4 | 444613 | PLUG |
| 5 | 15019179 | O RING |
| 6 | 9015056 | RING-BACKUP |
| 7 | 9068668 | TUBE |
| 8 | 9068667 | BOLT |
| 9 | 9079450 | PISTON |
| 10 | 9014093 | RING-WEAR |
| 11 | 9169669 | O RING |
| 12 | 9036867 | RING-BACKUP |
| 13 | 9079449 | RETAINER SEAL |
| 14 | 15233756 | SEAL |
| 15 | 9120034 | O RING |
| 16 | 186659 | BOLT |
| 17 | 9411010 | FITTING-GREASE |
| 18 | 9072925 | TUBE ASSEMBLY |
| 19 | 15255936 | RING WEAR |
| 20 | 9014235 | SEAL |
| 21 | 9256606 | WIPER |
| 22 | 9079451 | ROD PISTON |
| 23 | 169162 | BALL |
| 24 | 106671 | FILLING-RELIEF |
| 25 | 274209 | LOCKNUT |
| 26 | 9068666 | WASHER-HARDENED |
| 27 | 9019631 | WASHER-HARDENED |
| 28 | 9430339 | BOLT |
| 29 | 9014267 | DISC (1.00 IN) |
| 30 | 103332 | LOCK WASHER |
| 31 | 271613 | BOLT |
| 32 | 9017345 | KEY-SHEAR |
| GAS CIRCUIT | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 116436 | CONNECTOR |
| 2 | 9357564 | CONNECTOR |
| 3 | 9357565 | NUT |
| 4 | 103320 | LOCK WASHER |
| 5 | 15230572 | CONNECTOR ASSY |
| 6 | 9258624 | COUPLING |
| 7 | 9188747 | HOSE ASSY |
| 8 | 9136639 | NIPPLE |
| 9 | 2356564 | CHECK VALVE |
| 10 | 8040335 | ELBOW |
| 11 | 9402711 | CONNECTOR |
| 12 | 9160723 | COCK-DRAIN |
| 13 | 105405 | NIPPLE |
| 14 | 454145 | TEE |
| 15 | 116453 | ELBOW |
| 16 | 9128519 | HOSE ASSY |
| 17 | 9251514 | CROSS-PIPE |
| 18 | 2255197 | VALVE-SAFETY |
| 19 | 9021117 | TUBE |
| 20 | 2369508 | STUD-CLAMPING |
| 21 | 444029 | REDUCER |
| 22 | 179881 | BOLT |
| 23 | 103329 | LOCK WASHER |
| 24 | 9252512 | ELBOW |
| 25 | 118753 | ELBOW |
| 26 | 9377164 | PLATE |
| 27 | 18755 | ELBOW |
