Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
Terex earthmoving equipment parts
| 16 | 15244763 | COUPLING-SPLIEND |
| 17 | 9172766 | O RING |
| ACCUMULATOR-STEERING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6525035 | VALVE ASSY-RECHARGE |
| 2 | 274253 | O RING |
| 3 | 223453 | BOLT |
| 4 | 9036867 | RING-BACKUP |
| 5 | 9169669 | O RING |
| 6 | 9018820 | SEAL |
| 7 | 9018813 | PISTON |
| 8 | 9018819 | RING-WEAR |
| STEERING VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 457151 | BEARING |
| RELIEF VALVE-STEERING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15265078 | CARTRIDGE |
| STEERING CYLINDER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9014528 | CYLINDER-STEERING |
| 2 | 9014535 | TUBE |
| 3 | 9167506 | BEARING-SPHERICAL |
| 4 | 9425517 | RING-SNAP |
| 5 | 9014542 | ROD |
| 6 | 9256601 | WIPER |
| 7 | 9014532 | SEAL AND RING-BACKUP |
| 8 | 271565 | BOLT |
| 9 | 9256136 | RING-BACKUP |
| 10 | 9141862 | O RING |
| 11 | 9256074 | RING-PISTON |
| 12 | 274191 | LOCKNUT |
| 13 | 179883 | BOLT |
| 14 | 103329 | LOCKWASHER |
| 15 | 9261064 | STUD-BALL |
| 16 | 9018463 | RING-RETAINER |
| 17 | 9261065 | BUSHING |
| FILTER-STEERING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15266831 | ELEMENT |
| STEERING LINKAGE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15229005 | ROD END ASSY |
| 2 | 179839 | BOLT |
| 3 | 9018309 | PLATE |
| 4 | 9018310 | RING-RETAINER |
| 5 | 9253566 | BUSHING |
| 6 | 15015767 | PIN-BALL |
| 7 | 15228998 | ROD-END |
| 8 | 108580 | LOCKWASHER |
| 9 | 15229006 | ROD END ASSY |
| 10 | 103426 | PIN-COTTER |
| 11 | 9014408 | ROD-TIE |
| 12 | 271563 | BOLT |
| 13 | 9354243 | LOCKNUT |
| 14 | 444613 | PLUG |
| 15 | 9411019 | NIPPLE-GREASE |
| 16 | 15021796 | BELL CRANK |
| 17 | 9014414 | WASHER-THRUST |
| 18 | 15230265 | BUSHING |
| 19 | 9384855 | PIN |
| 20 | 15229654 | DISC |
| 21 | 9072942 | PIN-LOCKING |
| 22 | 9355772 | NUT |
| 23 | 223489 | BOLT |
| 24 | 15254413 | STEER ARM-LH |
| 25 | 15254412 | STEER ARM-RH |
| 26 | 9411010 | FITTING-GREASE |
| 27 | 15317485 | SEAL |
| 28 | 427667 | NUT |
| 29 | 15317486 | SEAL |
| 30 | 9016970 | NUT |
| 31 | 179097 | PIN-COTTER |
| 32 | 15250059 | PIN |
| 33 | 9060302 | PLATE |
| 34 | 179881 | BOLT |
| 35 | 103329 | LOCKWASHER |
| 36 | 9060288 | SPACER |
| STEERING COLUMN MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6430801 | NUT |
| 2 | 7150815 | WASHER |
| 3 | 15255304 | STEERING WHEEL |
| 4 | 179837 | BOLT |
| 5 | 103329 | LOCK WASHER |
| 6 | 179881 | BOLT |
| 7 | 9060202 | WASHER-HARDENED |
| 8 | 7160830 | LOCKWASHER |
| 9 | 15275116 | GAS STRUT ASSY |
| 10 | 15274171 | BUSH-PIVOT |
| 11 | 15275125 | SHOULDER BOLT |
| LINES AND FITTINGS-BODY HOIST | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 120378 | NUT |
| 2 | 103328 | LOCKWASHER |
| 3 | 103329 | LOCKWASHER |
| 4 | 108580 | LOCKWASHER |
| 5 | 179839 | BOLT |
| 6 | 179862 | BOLT |
| 7 | 179883 | BOLT |
| 8 | 179885 | BOLT |
| 9 | 179887 | BOLT |
| 10 | 179896 | BOLT |
| 11 | 9141918 | O RING |
| 12 | 9167602 | FLANGE-SPLIT |
| 13 | 9409982 | FLANGE-SPLIT |
| 14 | 9409983 | FLANGE-SPLIT |
| 15 | 9409984 | FLANGE-SPLIT |
| 16 | 9410968 | O RING |
| 17 | 9410969 | O RING |
| 18 | 9410970 | O RING |
| 19 | 15001428 | NUT-STACKING |
| 20 | 15001429 | CLAMP |
| 21 | 15014977 | BUSHING-SPLIT |
| 22 | 15004740 | BUSHING-SPLIT |
| 23 | 15004744 | BUSHING-SPLIT |
| 24 | 15004748 | NUT-STACKING |
| 25 | 15014975 | BUSHING-SPLIT |
| 26 | 15255483 | TUBE ASSY |
| 27 | 15001430 | CLAMP |
| 28 | 15004712 | CLAMP |
| 29 | 442733 | BOLT |
| 30 | 15303702 | HOSE ASSY |
| 31 | 15303701 | HOSE ASSY |
| 32 | 15255861 | HOSE ASSY |
| 33 | 15255862 | HOSE ASSY |
| 34 | 15255863 | HOSE ASSY |
| 35 | 15253230 | HOSE ASSY |
| 36 | 15255379 | HOSE ASSY |
| 37 | 15258074 | HOSE ASSY |
| 38 | 15258070 | HOSE ASSY |
| 39 | 15255346 | HOSE ASSY |
| 40 | 15236595 | TUBE ASSY |
| 41 | 15236504 | TUBE ASSY |
| 42 | 15258075 | TUBE ASSY |
| 43 | 15254568 | ADAPTOR |
| 44 | 15254569 | ADAPTOR |
| 45 | 15251994 | ADAPTOR-BULKHEAD |
| 46 | 15251950 | TEE |
| 47 | 15252869 | TEE |
| 48 | 15251936 | ADAPTOR |
| 49 | 15252906 | ELBOW |
| 50 | 15253129 | ELBOW |
| 51 | 15301272 | HOSE ASSY |
| 52 | 15251938 | ADAPTOR |
| 53 | 15252983 | ELBOW |
| 54 | 15247021 | BRACKET-TWISTED |
| 55 | 102635 | NUT |
| 56 | 9131877 | CLIP |
| SERVO CONTROL LINES-BODY | ||
