Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
Terex earthmoving equipment parts
| 001 001 15339987 EXTENSION-FENDER 002 001 15301646 FENDER ASSY-LH 003 001 15339993 FENDER ASSY-RH 004 001 15301612 PLATFORM ASSY-RH 005 001 15301686 CROSSMEMBER ASSY-FRONT 006 001 15301665 CROSSMEMBER ASSY-REAR 007 001 15254751 COVER PLATE ASSY 008 001 15313087 MUDGUARD 009 001 15248436 MUDGUARD A 010 001 15302636 HANDRAIL ASSY-LH B 011 001 15302451 HANDRAIL ASSY-RH 012 001 15249606 PLATE ASSY 013 002 06350625 BOLT (NSS KIT QTY) 014 001 09077400 MIRROR 015 002 15005357 BLOCK 016 002 09384350 SPACER 017 004 07150620 WASHER B 018 001 15302440 KICKSTRIP 019 002 06470601 LOCKNUT 020 006 00179883 BOLT 021 037 00179885 BOLT 022 003 00179887 BOLT 023 012 00179889 BOLT 024 002 00179892 BOLT A 025 001 15302635 KICKSTRIP 026 004 00179896 BOLT 027 004 00186656 BOLT 028 003 00186689 BOLT 029 004 00271623 BOLT 030 004 00271710 BOLT 031 002 00179881 BOLT 032 002 00103329 LOCKWASHER 033 034 00274209 LOCKNUT 034 004 09355771 NUT 035 001 15311451 PLATE COVER 036 002 00179883 BOLT 037 004 09019631 WASHER-HARDENED 038 008 09176228 WASHER-HARDENED |
039 004 09267949 WASHER-HARDENED 040 080 09270000 WASHER-HARDENED 041 010 09373547 PLUG 042 001 15246087 MIRROR-WIDE ANGLE 043 009 00274209 NUT 044 001 15302694 BENT PLATE 045 001 15302618 BRACKET-LH DOOR STOP 046 004 00179887 BOLT 047 008 09270000 WASHER-HARDENED 048 004 00274209 LOCKNUT 049 001 15343586 MIRROR ATTACHMENT ASSY 050 002 15304664 .PLATE 051 001 15304670 .ARM ASSY-MIRROR 052 002 15304663 .BAR-MIRROR MTG 053 001 15304704 .ROD ASSY 054 001 15304671 .BRACKET ASSY 055 003 00179820 .BOLT 056 003 00103320 .LOCKWASHER 057 003 00103340 .WASHER 058 002 00109084 .NUT 059 002 00103319 .LOCKWASHER 060 002 00103339 .WASHER 061 002 00179795 .BOLT 062 002 15302982 .U-BOLT 063 002 00102639 .NUT 064 001 15343194 BAR-EXTENSION 065 001 15308693 MIRROR 066 001 15301891 COVER PLATE 067 004 00115360 SCREW 068 001 15336533 FENDER EXTENSION 069 ASR 15248224 SPACER NOTES: A ITEM 25 KICKSTRIP PART OF ITEM 10 B ITEM 18 KICKSTRIP PART OF ITEM 11 |
| FROM SERIAL NO. T7831490 TO T7831532 | |
| SER.NO. SER.NO. NC REF QTY PART NO. DESCRIPTION FROM TO |
100-0070-7831 FENDERS AND MOUNTING
| STEERING LINKAGE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15229005 | ROD END ASSY |
| 2 | 179839 | BOLT |
| 3 | 9018309 | PLATE |
| 4 | 9018310 | RING-RETAINER |
| 5 | 9253566 | BUSHING |
| 6 | 15015767 | PIN-BALL |
| 7 | 15228998 | ROD-END |
| 8 | 108580 | LOCKWASHER |
| 9 | 15229006 | ROD END ASSY |
| 10 | 103426 | PIN-COTTER |
| 11 | 9014408 | ROD-TIE |
| 12 | 271563 | BOLT |
| 13 | 9354243 | LOCKNUT |
| 14 | 444613 | PLUG |
| 15 | 9411019 | NIPPLE-GREASE |
| 16 | 15021796 | BELL CRANK |
| 17 | 9014414 | WASHER-THRUST |
| 18 | 15230265 | BUSHING |
| 19 | 9384855 | PIN |
| 20 | 15229654 | DISC |
| 21 | 9072942 | PIN-LOCKING |
| 22 | 9355772 | NUT |
| 23 | 223489 | BOLT |
| 24 | 15254413 | STEER ARM-LH |
| 25 | 15254412 | STEER ARM-RH |
| 26 | 9411010 | FITTING-GREASE |
| 27 | 15317485 | SEAL |
| 28 | 427667 | NUT |
| 29 | 15317486 | SEAL |
| 30 | 9016970 | NUT |
| 31 | 179097 | PIN-COTTER |
| 32 | 15250059 | PIN |
| 33 | 9060302 | PLATE |
| 34 | 179881 | BOLT |
| 35 | 103329 | LOCKWASHER |
| 36 | 9060288 | SPACER |
| STEERING COLUMN MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6430801 | NUT |
| 2 | 7150815 | WASHER |
| 3 | 15255304 | STEERING WHEEL |
| 4 | 179837 | BOLT |
| 5 | 103329 | LOCK WASHER |
| 6 | 179881 | BOLT |
| 7 | 9060202 | WASHER-HARDENED |
| 8 | 7160830 | LOCKWASHER |
| 9 | 15275116 | GAS STRUT ASSY |
| 10 | 15274171 | BUSH-PIVOT |
| 11 | 15275125 | SHOULDER BOLT |
| LINES AND FITTINGS-BODY HOIST | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 120378 | NUT |
| 2 | 103328 | LOCKWASHER |
| 3 | 103329 | LOCKWASHER |
| 4 | 108580 | LOCKWASHER |
| 5 | 179839 | BOLT |
| 6 | 179862 | BOLT |
| 7 | 179883 | BOLT |
