Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
Terex earthmoving equipment parts
| 33 | 15244531 | BOLT |
| REAR RIDE CYLINDER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9079698 | REAR CYL ASSY |
| 2 | 9079696 | ROD |
| 3 | 9010661 | BUSHING |
| 4 | 9010662 | RING-SNAP |
| 5 | 9411010 | FITTING-GREASE |
| 6 | 9068666 | WASHER-HARDENED |
| 7 | 9013688 | VALVE-CHECK |
| 8 | 444613 | PLUG |
| 9 | 169162 | BALL |
| 10 | 9016787 | WIPER |
| 11 | 15237500 | SEAL |
| 12 | 9423349 | BOLT HEX 1.25-7 UNC |
| 13 | 9016784 | RING-BACKUP |
| 14 | 9016783 | O RING |
| 15 | 9016788 | RING-WEAR |
| 16 | 9079697 | PISTON |
| 17 | 9269710 | BOLT |
| 18 | 6525035 | VALVE ASSY-RECHARGE |
| 19 | 9030336 | RING-LARGE |
| 20 | 9034883 | CORE |
| 21 | 9217321 | WASHER-HARDENED |
| 22 | 9411019 | NIPPLE-GREASE |
| 23 | 9384151 | BOOT ASSY |
| 24 | 9139825 | CLAMP |
| 25 | 179837 | BOLT |
| 26 | 179883 | BOLT |
| 27 | 9015397 | SPACER |
| 28 | 15000838 | PIN-RIDE CYLINDER |
| 29 | 15019238 | BOLT |
| 30 | 15000991 | WASHER-HARDENED |
| 31 | 273852 | LOCKNUT |
| 32 | 9015398 | PIN ASSEMBLY |
| 33 | 103329 | LOCK WASHER |
| CABLES/HARNESSES-CAB | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15259091 | HARNESS,DASH |
| 2 | 15259105 | HARNESS,CAB |
| 3 | 15302853 | HARNESS,CONSOLE |
| 4 | 15302870 | TIMER RELAY |
| BATTERY AND CABLES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15305862 | MAGNETIC SWT-START SOL |
| 2 | 15253875 | CLAMP-PIPE |
| 3 | 15302350 | CABLE ASSEMBLY |
| 4 | 15302353 | CABLE ASSEMBLY |
| 5 | 15256097 | CABLE ASSY |
| 6 | 15232468 | CABLE |
| 7 | 15302354 | CABLE ASSEMBLY |
| 8 | 15302355 | CABLE ASSEMBLY |
| 9 | 15256096 | CABLE ASSY |
| 10 | 15256094 | CABLE ASSY |
| 11 | 15258745 | COVER ASSEMBLY |
| 12 | 6350612 | SCREW |
| 13 | 102635 | NUT T50 |
| 14 | 103320 | LOCKWASHER |
| 15 | 179845 | BOLT |
| 16 | 7160630 | WASHER |
| 17 | 108580 | LOCKWASHER |
| 18 | 103319 | LOCKWASHER |
| 19 | 15304322 | CABLE ASSEMBLY |
| 20 | 15258443 | ISOLATOR RELAY |
| 21 | 15310266 | PLATE-MTG |
| 22 | 103340 | WASHER |
| 23 | 103320 | WASHER-LOCK |
| 24 | 179795 | BOLT |
| 25 | 103319 | WASHER |
| BATTERY MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 179890 | BOLT |
| 2 | 9270000 | WASHER-HARDENED |
| 3 | 9263815 | CLAMP-BATTERY |
| 4 | 15236524 | BOLT |
| 5 | 9060202 | WASHER-HARDENED |
| ELECTRICAL LIGHTING SYSTEM | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15230426 | HEADLAMP |
| 2 | 15271433 | BULB-H4 |
| 3 | 15258783 | LAMP-SIDE INDICATOR |
| 4 | 15258873 | BULB-H4 |
| 5 | 15258872 | BULB-24V 21W H/DUTY |
| 6 | 15273641 | LAMP-REVERSE |
| 7 | 15273642 | BULB-24V 70W HALOGEN |
| 8 | 15273643 | LAMP-RETARDER |
| 9 | 15273644 | LAMP-DIR/STOP/TAIL |
| 10 | 15273718 | HARNESS-REAR LIGHTS |
| 11 | 102634 | NUT |
| 12 | 103320 | LOCKWASHER |
| 13 | 108580 | LOCKWASHER |
| 14 | 106263 | WASHER |
| 15 | 117966 | GROMMET |
| 16 | 102635 | NUT |
| ALTERNATOR AND MOUTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15273449 | ALTERNATOR-24V/65A |
| STARTER MOTOR | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15273450 | STARTER |
| REVER ALARM | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15001878 | ALARM-REVERSE |
| 2 | 455537 | BOLT |
| 3 | 274208 | LOCKNUT |
| SWITCHES AND SENSORS | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15300082 | SWITCH-PRESSURE |
| 2 | 15300083 | SWITCH-PRESSURE |
| 3 | 15300084 | SWITCH-PRESSURE |
| 4 | 15300085 | SWITCH-PRESSURE |
| 5 | 15300086 | SWITCH-PRESSURE |
| 6 | 15300087 | SWITCH-TEMPERATURE |
| 7 | 15300090 | SWITCH-PRESSURE |
| 8 | 15300089 | SWITCH-TEMPERATURE |
| 9 | 15300088 | SWITCH-PRESSURE |
| 10 | 15303318 | SWITCH-PRESSURE |
| 11 | 15300116 | SWITCH-PRESSURE |
| 12 | 15301960 | SENDER-TEMPERATURE |
| 13 | 15300118 | SENDER-TEMPERATURE |
| 14 | 15300119 | SENDER-PRESSURE |
| 15 | 15236152 | SWITCH-LEVEL FLOAT |
| 16 | 15259165 | SWITCH ASSY-BODY UP |
| 17 | 103339 | WASHER |
| 18 | 15227711 | SEAL |
| 19 | 15301169 | SEAL |
| 20 | 15301115 | ADAPTER |
| 21 | 15301114 | ADAPTER |
| 22 | 15304214 | ELBOW |
| 23 | 15310396 | SWITCH-TEMP |
| RADIO CASSETTE AND SPEAKERS | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 106263 | WASHER |
| 2 | 108580 | LOCKWASHER |
| ELECTRICAL HORN | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15303068 | HORN |
| 2 | 15303069 | HORN |
| FUEL TANK AND MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15255485 | TANK ASSEMBLY-FUEL |
| 2 | 179883 | BOLT |
| 3 | 103329 | LOCKWASHER |
| 4 | 273469 | PLUG |
| 5 | 9251163 | CAP ASSY |
| 6 | 9251092 | GASKET |
| 7 | 9183385 | GASKET |
| 8 | 9027836 | GASKET |
| 9 | 9049192 | DIAL |
| 10 | 9141915 | O RING |
| 11 | 9268885 | LOCKWASHER |
| 12 | 9122167 | CONNECTOR |
| 13 | 9129561 | HOSE ASSY |
| 14 | 187396 | COUPLING |
| 15 | 6750967 | CAP-BREATHER |
| 16 | 15234879 | STRAP |
| 17 | 9355771 | NUT |
| 18 | 223452 | BOLT |
| 19 | 9250715 | WASHER-HARDENED |
| 20 | 9419493 | NUT |
| 21 | 9160607 | STRAINER |
| FUEL LINES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15227369 | HOSE ASSY |
| 2 | 15256641 | HOSE ASSY (R).62MPHT |
| 3 | 9402828 | ELBOW |
